ZKBio900 Series
- 15" Bezel-Free True-Flat PCAP touch screen
- Fingerprint verification
- Dual hinge stand, table stand and standard VESA mount
- Power-efficient Intel® Celeron® J1900 2.0 GHz Quad-Core processor
- 15” Bezel-Free True-Flat PCAP touch screen
- Optional Intel® Core™ i3 or i5 processor
- Fingerprint verification makes transactions safer
- Modular design with aluminum alloy material
- Dual hinge stand, table stand, and standard VESA mount
- VFD and second display can be adjusted in angle;
- Easy to hide cables and a fanless design
| Model Name | ZKBio910 ZKBio930 ZKBio950 |
SYSTEM |
|
| CPU | ZKBio910：Intel Celeron J1900 @ 1.99GHz ZKBio930：Intel Core i3-4030U @ 1.70GHz ZKBio950：Intel Core i5-4210U @ 1.70GHz |
| System Memory | 4GB Standard, DDR3L 1666MHz |
| Storage Device | 64GB SSD Standard, 1*2.5’’ HDD & 2.5’’ SSD |
| OS Supported | Windows 7, Windows 8, Windows 10 IoT Enterprise, POS Ready 7, Linux |
| Audio | Realtek ALC662 |
DISPLAY AND TOUCH |
|
| Type | 15’’ TFTLCD, LED Backlight |
| Resolution | 1024*768 |
| Touch Screen | Projected capacitive touch screen |
|
Customer Display |
LED (8C digital tube) |
EXTERNAL I/O PORTS |
|
|
VGA |
1*DB-15 |
|
USB |
ZKBio910：5*USB 2.0 & 1*USB 3.0 ZKBio930：2*USB2.0 & 4*USB3.0 ZKBio950：2*USB2.0 & 4*USB3.0 |
|
COM |
2 |
|
HDMI |
1 |
|
LAN |
1 |
|
Audio |
1*line-out |
PHYSICAL ENVIRONMENT |
|
|
Operating Temperature |
0℃ ~ 35℃ at 20% - 80% humidity |
|
Storage Temperature |
20℃ ~ 55℃ at 20% - 80% humidity |
|
Power Supply |
Adaptor 12V DC 5A |
|
Dimensions (W*H*D) |
228*385*403 mm |
|
Certifications |
CE, FCC |
|
Material |
Aluminum alloys, ABS |
|
Color |
Black |
OPTIONS & PERIPHERALS |
|
|
2nd Display |
9.7 inch TFT LCD |
|
Customer Display |
20 columns * 2 lines |
|
MSR |
3 tracks |
|
Barcode |
2D barcode scanner |
|
Fingerprint Reader |
USB fingerprint module |
